详细说明
| ds(MHz)： |
BM817C: FDD-LTE:B1/B3/B5/B8 TDD-LTE:B38/B39/B40/B41(120M) HSPA/UMTS:B1/B5/B8 EVDO/CDMA:BC0 GSM/GPRS/EDGE:B3/B8 BM817C-E1: FDD-LTE:B1/B2/B3/B5/B7/B8/B20 TDD-LTE:B38/B40/B41(120M) HSPA/UMTS:B1/B2/B5/B8 GSM/GPRS/EDGE:B2/B3/B5/B8 BM817C-A1: FDD-LTE:B2/B3/B4/B5/B12/B17/B25/B26/B66 TDD-LTE:B41(200M) HSPA/UMTS:B2/B4/B5 GSM/GPRS/EDGE:B2/B5 BM817C-T1: FDD-LTE:B1/B2/B3/B5/B7/B8/B28 TDD-LTE:B38/B40/B41(200M) HSPA/UMTS:B1/B2/B5/B8 GSM/GPRS/EDGE:B2/B3/B5/B8 |
| Dimensions： | 51.0*30.0*4.7 |
| Power Supply： | 3.3V~4.2V |
| Operating Temperature： | -40℃~ +85℃ |
详细介绍
| DATA TRANSMISSION | |
| Peak Rate(DL/UL) | 150Mbps/50Mbps（BM817C-H1 75Mbps/50Mbps） |
| 4G | LTE Cat.4 |
| ENHANCED FEATURES | |
| TTS | √ |
| DTMF | √ |
| FOTA | √ |
| GNSS | √ |
| Open CPU | √ |
| RIL for Android | √ |
| VOLTE | √ |
| HTTP/HTTPS/FTP/FTPS/SMTP/POP3/DNS/MMS | √ |
| Dual-Uart | √ |
| Gobinet | √ |
| Linux QMI Driver | √ |
| NDIS | √ |
| SIM Detection | √ |
| CERTIFICATIONS | √ |
| Certifications | CTA/3C/CE/FCC |
